USB 3.0 PCI-E Express 1x to 16x Extender Riser Card Adapter

Increase the speed and efficiency of your computer with the USB 3.0 PCI-E Express 1x to 16x Extender Riser Card Adapter. This adapter allows you to connect a 16x PCI-E card to a 1x slot, providing faster data transfer rates and improved performance. Upgrade your system easily and enjoy faster data transfer speeds.

6pin Features:
1. 100% Brand new and high quality.
2. Using 60cm USB 3.0 cable as extender cable ,premium quality and super speed.
3. With 4x FP solid capacitors, making graphics power supply more stable and secure.
4. With SATA 15pin Male to 6pin power cable,more powerful,and reduce the burden of the motherboard.
5. Gold plated contacts for better connectivity and long life .
6. Compatible with 1x,4x,8x,16x PCI-E slot of the motherboard.
7. With side clip to fasten other card.
8. No driver needed.
9. Dedicated for bitcoin mining.
10. Board size: approx.12.8cm*4.2cm*1.0cm/5.03*1.65*0.39''
11. Color: Blue

12. USB Cable Length: approx.60cm


4 pin Features:
3 FP sold capacitors as stable graphic card power supply.
Extender cable with 4pin port (16A power supply) to enhance power. Solving problems caused by shortage in power supplying.
With original connectors on the card.
PCI-E connector enable you to connect 3M without signal damping.
With enhanced shielding CDRH127R 12 X 12 X 7MM 33uH 330 for better conductivity.
Soft cable, easy and convenient to carry.
Gold plated contacts for better connectivity and long life.
With holder buckle to easily install or remove the graphic card.
Solved problems like burning soldering point, signal damping, not enough length, etc.
Compatible with 1X, 2X, 4X, 8X, 16X. (suitable for 1-16X and 16-16X)
No drivers needed for installation.
Designed for mining Bitcoin.

Specification:
Cable Length: approx. 60 cm/23.62"
Net Weight: approx. 84 g
Port: PCI-E 1X
Size: approx. 128 X 42 X 10 mm/5.03*1.65*0.39"
Buckle Color: white

PCIE 1 to 4 USB Adapter Card Feature:

4 Slots brings great extendability.
Plugs directly to the board without any extender cable, can be fixed to the case.
PCI-E slot power solution, no extra power cable needed.
Only one cable to the slot, easy and convenient to settle and install.
With IC heat radiator.

Specification:
Bus Port: PCI-E
Port Quantity: 4 X PCI-E USB
Size: approx. 120 X 66 X 21 mm/4.72 X 2.6 X 0.83"
Net Weight: approx. 41 g
Gross Weight: approx. 73 g
Package Size: approx. 130 X 90 X 25 mm/5.12 X 3.54 X 0.98"
Supported OS: DOS, Linux, Windows XP/7/8/10
Note: Riser card is not include


Notes: Please allow 1-3cm error due to manual measurement and there will be different color as different display, please understand. Thanks.
